Installation

Routing instructions have been divided into two parts due to the different requirements. (E500 and lifestyle have different aspects)

E500/ Range FAQs

How do I install the tiles?

Please refer to the installation instructions below. There are also several installation videos.

Kann ich die Fliesen direkt nach der Anlieferung verlegen?

The tiles must first be brought to room temperature. We recommend that you wait 24 hours before laying. If you do not have that much time, you can take the tiles off the pallet. This allows you to adapt to room temperature faster.

Installation should not be below 15ºC.

PLEASE NOTE: If you need to lay the tiles at 15 º C, leave a larger edge to the fix points or insert on an extension piece every 8 to 10 meters. We can not guarantee you have a warranty on floors that are below 15 ºC.

Kann ich die Fliesen im Freien installieren?

No, the E500 can not be installed outdoors. Fluctuating temperatures cause PVC to expand and contract. This will cause the edges of your tile to deform.

Welches Werkzeug benötige ich?

You do not need a special tool. For easier installation, have a tape measure, metal ruler, rubber mallet or light hammer, a chalk line scooter, and cutting tools (if necessary) at hand.

Wie kann ich die Teile schneiden?

There are several options available for cutting tiles. We recommend a cutting machine for larger surfaces. You can also use an electric band saw, a table saw or a saw with a wooden blade. The tiles can thus be cut with a utility knife, which is much more exhausting than the other dicing techniques.
You can borrow a tool from a hand if you do not have a tool at hand.

Muss ich die Fliesen auf dem Boden festkleben?

For most of the floors, extra gluing is not necessary. The following points are exceptions. For the majority of the floors an extra bonding is not necessary. The following points are exceptions.

  • If there is a vehicle with a very high point load, for example, a tricycle electric power truck with the batteries over the rear wheel.
  • If parts of the soil are exposed to much higher temperatures than the rest of the soil.
  • If parts of the soil are exposed to much higher temperatures than the rest of the soil.
  • If the floor is exposed to direct sunlight (usually with south windows and bulges). If you need to glue the floor, we recommend Uzin MK92S.

Wie muss der vorhandene Boden für Ecotile vorbereitet werden?

In most cases, no special preparation is necessary. Ecotile can easily be disposed of and contaminated.

We recommend that you sweep the floor to remove loose parts.

No repairs are required unless there are large cracks or missing pieces of cement. There is no waste coating, sealing or washing necessary.

Kann ich diese Fliesen über einen gestrichenen, Vinyl oder Teppichboden verlegen?

  • • Painted Floor: Painted FloorNo Problem – Lay the floor as described
  • Vinyl floor so no problem – just follow the simple installation instructions
  • CarpetingStrong, that’s good – but we recommend to remove the carpet if possible

Wie werden die Fliesen auf Böden mit einer Fußbodenheizung installiert?

Please make sure that the underfloor heating is switched on and has the correct operating temperature before you start laying. Lay the tiles over the entire surface, but leave a border on the walls free.
The tiles should be acclimatized for the next 24 hours when the heater is on. Then you can lay the tile surface to the edge or to the end point.

Do I need to use a sealant?

No, extra sealer is not necessary. However, we would like to make it clear and give the floor a light, pleasant.

Ecotile Lifestyle FAQs

Wie installiere ich die Fliesen?

Please refer to the installation instructions below. There are also several installation videos

Kann ich die Fliesen direkt nach der Anlieferung verlegen?

Yes.

Welches Werkzeug benötige ich?

You do not need special tools For easy installation, we recommend that you have a measuring rod and a cutting tool (if necessary) at hand.

Wie kann ich die Teile schneiden?

You can cut the tiles with a jigsaw, hacksaw or band saw.

Benötige ich Klebstoff beim Verlegen?

No, the tiles were equipped with appropriate expansion joints. So the floor will not change or move, so gluing is not necessary.

Kann ich die Fliesen draußen installieren?

Absolute. Ecotile lifestyle was developed for outdoor use and can withstand all temperature and climate change

Kann ich die Fliesen direkt auf Gras verlegen?

No, if you want to lay the tiles on a grassy surface, sand (stone powder) must first be applied to compact the surface. Then a geotextile (eg Tencate PP15 or similar) must be laid with a fine structure. The tiles can only be laid on hard surfaces.

Wie bereite ich einen bestehenden Boden für das Verlegen vor?

In most cases, no special preparation is necessary. Ecotile can easily be disposed of and contaminated.
We recommend that you sweep the floor to remove loose parts.
No repairs are required unless there are large cracks or missing pieces of cement.

Wie kann ich Linien oder Markierungen auf meinen Ecotile Lifestyle Sport-Belag aufbringen?

You can use cables to create straight lines between tiles. However, you have to paint curved lines yourself.
Use a paint that adheres well to polypropylene, search as Maraprop PP. Clean the surface before applying the paint. Use masking tape to delineate the lines and markings and a scooter. At least two layers are necessary.
You can hire a professional line painter if you are not sure.

Wie verwende ich Lifestyle Kabelstreifen?

If you want to cover cables, run them along the side of a tile and install the cable strip over the cable. Simply attach another tile to the other side of the cable.

Können Sie die Fliesen für mich installieren.

Yes, we have a special team in the UK. that can install your lifestyle for you. Installation fees not included.
